HLL36050LV - Square D 50A 600VAC 3 Pole PowerPacT H Frame Circuit Breaker Thermal Magnetic

HLL36050LV

HLL36050LV is a Square D PowerPacT H Frame circuit breaker rated for 50 amps, 600 volts AC, and 3 poles with thermal magnetic trip protection.This molded case circuit breaker features a 50kA interrupt rating at 600VAC, dual-break rotating contacts to reduce peak current during short circuits, and an integral push-to-trip button. It is designed for unit mount installation with lugs on both line and load sides and includes a control wire terminal on the load end. The breaker complies with UL, CSA, NOM, IEC standards, and is CE marked.

• Amperage: 50A
• Voltage Rating: 600VAC
• Poles: 3
• Frame/Series: PowerPacT H Frame
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 50kA at 600VAC
• Mounting Type: Unit Mount
• Lugs on line and load sides
• Control wire terminal on load end
• Certifications: UL, CSA, NOM, IEC, CE Marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLL36050LV
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Temp Rating : 28-158 °F (-2-70 °C)

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.156
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
