2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HLD2500
HLD2500 is a complete Eaton Series C L-Frame molded case circuit breaker designed for reliable protection in demanding electrical environments. This breaker features a fixed thermal and fixed magnetic trip unit for consistent performance and safety. The Eaton HLD2500 is rated for 500 amperes and 600 volts AC, with a 250 volt DC rating. It is a two-pole breaker with an L-Frame design, suitable for both line and load connections. The unit is built for high interrupt capacity, supporting up to 100 kAIC at 240 volts and 65 kAIC at 480 volts. It is compatible with 50/60 Hz systems and is constructed with aluminum for durability.
- Part Number: HLD2500
- Manufacturer: Eaton
- Series/Frame: Series C L-Frame
- Amperage: 500A
- Voltage: 600V AC, 250V DC
- Poles: 2
- Mounting Type: Line and Load
- Interrupt Rating: 100 kAIC at 240V, 65 kAIC at 480V
- Frequency: 50/60 Hz
- Trip Unit: Fixed Thermal, Fixed Magnetic
- Material: Aluminum
- HACR Rated
Specifications
- Part Number: HLD2500
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HLD
- Voltage : 600
- Amperage : 500
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679042403
- GTIN : 00786679042403
- Country of Origin : United States
- Dimensions : 13.1 in x 10.2 in x 10.2 in (Length/Depth x Height x Width)
- Weight : 19
- Certification : UL Listed
