Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HLD2300
HLD2300 is a 300 Amp, 600 Volt, 2-Pole molded case circuit breaker from Westinghouse Series C family designed for reliable circuit protection.This Westinghouse HLD2300 breaker features a 2-pole design with a 300A continuous current rating and 600V AC voltage rating. It has a molded case construction and is suitable for low voltage distribution systems. The breaker offers a high interrupting rating of 65kA at 480V and uses a thermal magnetic trip unit for dependable overload and short circuit protection. It is bolt-on or feed-thru mountable, compatible with Eaton/Cutler Hammer equipment, and UL listed for safety compliance.
- Key Specifications
- Amperage: 300 Amps
- Voltage: 600 Volts AC
- Poles: 2
- Interrupting Rating: 65,000 AIC @ 480V
- Series/Frame: Series C
- Trip Unit: Thermal Magnetic
- Mounting Type: Bolt-on / Feed Thru
- Certifications: UL Listed
Specifications
- Part Number: HLD2300
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HLD
- Voltage : 600
- Amperage : 300
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 20
