2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HKD3250T56WPN
HKD3250T56WPN is a 250 amp, 600 volt, 3-pole molded case circuit breaker from Eaton's Series C HKD line.This Eaton Cutler Hammer Westinghouse circuit breaker features a K-frame design with a T172 trip unit, optimized for reliable protection in industrial and commercial power distribution. It supports up to 65 kA interrupt rating at 600 VAC and 250 VDC, suitable for demanding electrical environments. The breaker is designed for mounting without terminals and complies with relevant UL and CSA certifications.
- Key Specifications
- Amperage: 250 A
- Voltage Rating: 600 VAC, 250 VDC
- Poles: 3
- Series/Frame: Series C, K-frame
- Trip Unit: T172
- Interrupt Rating: 65 kA at 600 VAC
- Mounting Type: Without terminals
- Certifications: UL, CSA
- Weight: Approx. 11.5 lbs
- Dimensions: 5.5" H x 5.5" W x 4.1" L
- Part Number: HKD3250T56WPN
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 250
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Protection : Magnetic Only
- UPC : 078211352932
- Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 11.5
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
