HJL36150AACA - Square D 150A 600V 3-Pole PowerPact H Thermal Magnetic Circuit Breaker

HJL36150AACA

HJL36150AACA is a Square D PowerPact H series thermal magnetic circuit breaker rated for 150 amps and 600 volts AC with 3 poles.HJL36150AACA features a unit mount design with a D interrupt rating code, providing 25 kA at 240 V AC, 18 kA at 480 V AC, and 14 kA at 600 V AC. It supports 250 V DC operation at 20 kA interrupt rating. The breaker is UL Listed, CSA certified, and IEC rated, suitable for industrial and commercial power distribution applications.

Key Specifications
• Amperage: 150 A
• Voltage Rating: 600 V AC, 250 V DC
• Number of Poles: 3
• Mounting Type: Unit Mount
• Interrupt Rating: 25 kA @ 240 V AC, 18 kA @ 480 V AC, 14 kA @ 600 V AC, 20 kA @ 250 V DC
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA, IEC, CE
• Wire Gauge: AWG 14 to 3/0 Aluminum/Copper
• Dimensions (HxWxD): 6.4 x 4.12 x 4.36 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL36150AACA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Temp Rating : 28-158 °F (-2-70 °C)

Product Data

• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
