Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HJL36050CA
HJL36050CA is a Square D Powerpact H-Frame molded case circuit breaker rated for 50 amps, 600 volts, and 3 poles with thermal magnetic trip unit technology.This circuit breaker features a 65kA interrupt rating at 480V and 25kA at 600V, designed for unit mount lug installation with line and load side lugs. It includes long-time and instantaneous trip functions, is UL 489 listed, and suitable for three-phase power protection applications.
- Amperage: 50A
- Voltage: 600VAC / 250VDC
- Poles: 3
- Frame Type: H-Frame
- Mounting: Unit mount lug
- Interrupt Rating: 65kA @ 480V, 25kA @ 600V
- Trip Unit: Thermal magnetic with LI (Long-Time and Instantaneous)
- Connection: Line and load side lugs
- UL Listed: UL 489
- Continuous Current Rating: 80%
- Magnetic Hold Current: 350A
- Phase: 3
Specifications
- Part Number: HJL36050CA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Temp Rating : 28-158 °F (-2-70 °C)
Product Data
- Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
