Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HJD2250F
HJD2250F is a Westinghouse 2 pole, 250 amp, 600 Volt Series C circuit breaker with a 65kA interrupt rating at 480V and bolt-on mounting.This industrial-grade molded case circuit breaker features a thermal-magnetic trip unit and is designed for reliable protection in electrical distribution systems. It supports a 250 amp continuous current rating and is rated for 600 VAC operation. The breaker frame is Series C, J-frame type, providing robust performance and interchangeability with compatible trip units.
- Manufacturer: Westinghouse
- Part Number: HJD2250F
- Amperage: 250A
- Voltage Rating: 600V AC
- Number of Poles: 2
- Interrupt Rating: 65kA at 480V
- Mounting Type: Bolt-On
- Series/Frame: Series C, J-frame
- Trip Unit: Thermal-magnetic
- Certifications: Industrial standard compliance
Additional Information
This item is Frame only as definded by the part number. That means it is only the circuit breaker frame, and no lugs or trip unit is included with the frame.
Specifications
- Part Number: HJD2250F
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HJD
- Voltage : 600
- Amperage : 250
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Protection : Thermal Magnetic
Product Data
- UPC : 78667951205
- GTIN : 00786679512050
- Country of Origin : Dominican Republic
- Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 11.25
- Certification : UL Listed
