HJA260204 - Square D 20 Amp 600 Volt 2 Pole Thermal Magnetic Circuit Breaker I-Line Style

HJA260204

This circuit breaker features a high interrupting rating of 100kA at 240VAC, 65kA at 480VAC, 25kA at 600VAC, and 20kA at 250VDC. It includes long time and instantaneous trip functions and is UL, CSA, CE, and IEC certified. The breaker is designed for use in PowerPact H frame panels and supports wire gauges from AWG 14 to 3/0 aluminum or copper conductors.

Key Specifications
• Amperage: 20 A
• Voltage Rating: 600 V AC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 100 kA at 240 V AC, 65 kA at 480 V AC, 25 kA at 600 V AC, 20 kA at 250 V DC
• Frame Type: H (PowerPact H)
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Functions
• Approvals: UL, CSA, CE, IEC
• Phase: Single Phase
• Wire Gauge Compatibility: AWG 14 to 3/0 Aluminum/Copper
• Dimensions: 9.73 in H x 4.8 in L x 2.94 in W
• Temperature Rating: 104 °F (40 °C)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: HJA260204
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 785901939122
• GTIN : 00785901939122
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
