HGL26070 - Square D 70A 600V 2-Pole Thermal Magnetic Molded Case Circuit Breaker PowerPact H Frame

HGL26070

HGL26070 is a Square D PowerPact H Frame molded case circuit breaker rated for 70 amps and 600 volts AC, designed for reliable thermal magnetic protection.This 2-pole breaker features a thermal magnetic trip unit with long-time and instantaneous protection, suitable for feed-thru connections and reverse fed applications. It has a high interrupting capacity of 35kA at 480V and is UL, CSA, and CE certified. The breaker measures 3.39 x 4.09 x 6.42 inches and is part of the I-Line PowerPact H series.

• Amperage: 70A
• Voltage Rating: 600 VAC, 250-500 VDC
• Poles: 2
• Mounting Type: Unit Mount
• Interrupt Rating: 35kA @ 480V
• Series/Frame: PowerPact H Frame
• Trip Unit: Thermal Magnetic (LI - Long-Time and Instantaneous)
• Connection: Feed-Thru
• Certifications: UL 489, CSA, CE
• Dimensions (HxWxD): 3.39 x 4.09 x 6.42 inches
• Weight: Approx. 4.85 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGL26070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGL
• Voltage : 600
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 150A/HG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 3 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable

Product Data

• UPC : 785901598800
• GTIN : 00785901598800
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
