Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD3150K
HFD3150K is an Eaton Series C F-frame molded case switch with fixed thermal-magnetic trip.
- Amperage Rating: 150 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: 3
- Frame Type: F
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
- Frequency Rating: 50/60 Hz
- Connection Type: Bolt-On
- Certifications: UL Listed
Specifications
- Part Number: HFD3150K
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : NA - No Overcurrent Protection
- Frame Size : F Frame
- Protection : Non-Automatic
Product Data
- UPC : 782114860458
- GTIN : 00782114860458
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.2
- Certification : UL Listed
