Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD3035WBP10
HFD3035WBP10 is a Series C F-frame molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial power distribution systems.This three-pole circuit breaker features a fixed thermal and fixed magnetic trip unit, rated for 35 amps and 600 VAC. It is built for load-side mounting and offers high interrupt capacity for demanding applications. The breaker is compatible with a wide range of Eaton accessories and is suitable for use in standard and harsh environments.
- Series C F-frame design
- 35A amperage rating
- 600 VAC maximum voltage
- Three-pole configuration
- Fixed thermal/fixed magnetic trip unit
- 100 kAIC interrupt rating at 240 VAC
- 65 kAIC interrupt rating at 480 VAC
- Load-side mounting
- 50/60 Hz frequency rating
- UL listed
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: HFD3035WBP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 35
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
