HFD3025WBP10 - Eaton Series C 3-Pole 25A 600V Molded Case Circuit Breaker

HFD3025WBP10

HFD3025WBP10 - Eaton Series C F-frame molded case circuit breaker with fixed thermal-magnetic trip, 3-pole, 25A rating.

Eaton HFD3025WBP10 is a complete Series C molded case circuit breaker featuring HFD design, F-frame, three poles, 25A amperage, 600 Vac / 250 Vdc voltage rating, and fixed thermal-magnetic trip type T186. It provides cable in/cable out mounting with load side terminals and 50/60 Hz frequency rating. Interrupt ratings include 100 kAIC at 240 Vac and 65 kAIC at 480 Vac. UL Listed certification ensures reliable circuit protection.

Key Specifications

• Amperage Rating: 25 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: Three-pole
• Circuit Breaker Type: HFD
• Frame: F-frame
• Series: Series C
• Trip Type: Fixed thermal-magnetic (T186)
• Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
• Frequency Rating: 50/60 Hz
• Terminals: Load side
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HFD3025WBP10
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 600 AC
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 4
