Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HFD2125L
HFD2125L - Westinghouse 2-pole molded case circuit breaker rated at 125A and 600V.The HFD2125L is a Series C F-frame thermal magnetic circuit breaker with feed-thru connection, designed for reliable overcurrent protection in industrial applications.
- Amperage: 125A
- Voltage: 600VAC, 250VDC
- Poles: 2
- Frame: F Frame
- Series: Series C
- Type: HFD
- Connection: Feed-Thru
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 100kA@240VAC, 65kA@480VAC, 25kA@600VAC, 22kA@250VDC
Specifications
- Part Number: HFD2125L
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 125
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679850602
- Country of Origin : Dominican Republic
- Dimensions : 7.5 in x 3.5 in x 5 in (Length/Depth x Height x Width)
- Weight : 3.5
- Certification : UL Listed
