HFD2040L - Westinghouse 2-Pole 40A 600V Molded Case Circuit Breaker Series C

HFD2040L

HFD2040L is a two-pole, 40-ampere, 600-volt molded case circuit breaker from Westinghouse, part of the Series C family with F-frame construction and fixed thermal-magnetic trip unit. This complete breaker is designed for industrial and commercial power distribution applications, featuring high interrupting capacity ratings and reliable overcurrent protection. The unit operates at 40 degrees Celsius and includes feed-thru terminals for flexible installation in electrical panels and switchboards.

• Poles: 2
• Amperage: 40A
• Voltage: 600V AC, 250V DC
• Series: Series C
• Frame: F-frame
• Trip Unit: Fixed thermal-magnetic
• Interrupt Rating: 100 kAIC at 240V AC, 65 kAIC at 480V AC
• Type: HFD
• Phase: Single-phase
• Operating Temperature: 40 degrees Celsius
• Configuration: Complete breaker with feed-thru terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HFD2040L
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 600 AC
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679451786
• GTIN : 00786679451786
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 3.5 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3.5
• Certification : UL Listed
