HF462J - Siemens 60 Amp 600 Volt 4-Pole Fusible Safety Switch NEMA 12

HF462J

HF462J is a heavy-duty fusible safety disconnect switch designed for industrial power distribution and motor control applications.

This 4-pole, 4-fuse safety switch is rated for 600 VAC at 60 amperes and is housed in a NEMA 12 industrial enclosure. The switch features a double-break visible blade design with single-throw operation and is suitable for 3-phase systems. It includes a groundable neutral block factory installed and voidable dual cover interlocks standard on all heavy-duty switches to prevent accidental cover opening during operation. The switch is load break and horsepower rated, making it suitable for motor disconnect and branch circuit protection in industrial environments.

• Voltage Rating: 600 VAC
• Amperage: 60A
• Poles: 4 (3-phase + neutral)
• Enclosure Type: NEMA 12
• Fuse Type: 4-Fuse Fusible
• Contact Style: Single Throw (ST)
• Horsepower Rated: 15 hp at 240V, 50 hp at 600V
• Short Circuit Withstand: 200 kA RMS symmetrical at 600V AC (30-200A range)
• Blade Design: Double-break visible blade
• Neutral Block: Groundable, factory installed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HF462J
• Manufacturer : Siemens
• Brand : Siemens
• Category : Switch
• Item Subcategory : Disconnect
• Section : Fusible Disconnect Switch
• Family : VBII Series
• Type : HF
• Voltage : 600 AC AC
• Amperage : 60
• Phase : 3
• Poles : 4
• AIC rating : 200kA@600V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Fuse Class : R
• Wire : 4
• Configuration : Single
• Coil Voltage Maximum : 48
• Coil Voltage Minimum : 48
• Switch Style : Fusible
• Nema Rating : NEMA 12
• Protection : Solid State
• Compatible Frames : PGP

Product Data

• UPC : 783643488366
• Country of Origin : Mexico
• Weight : 4.7
• Certification : UL listed
