2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HEG3B070L
HEG3B070L is a Siemens 3-pole molded case circuit breaker rated for 70 amps and 600 volts AC with a thermal magnetic trip unit.
This circuit breaker belongs to the Siemens EG frame series and features a high interrupting capacity with an interrupt rating of 25 kA at 600Y/347V and 65 kA at 480V. It is UL, IEC, CSA, and NOM certified and designed for load end standard copper/aluminum lug connections. The breaker provides reliable protection with long time and instantaneous trip functions suitable for various industrial and commercial applications.
- Key Specifications
- Amperage: 70 Amps
- Voltage Rating: 600 VAC
- Number of Poles: 3
- Interrupt Rating: 25 kA at 600Y/347V, 65 kA at 480V
- Frame/Series: EG Frame
- Trip Unit: Thermal Magnetic
- Mounting Type: Molded Case
- Certifications: UL, IEC, CSA, NOM
- Connection Type: Load End Standard CU/AL Lugs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: HEG3B070L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : VL Series
- Type : HEG
- Voltage : 600
- Amperage : 70
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : EG Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 783643520493
- GTIN : 00783643520493
- Country of Origin : Dominican Republic
- Dimensions : 6.693 x 3.937 x 4.724 inch
- Weight : 2.998
