HED41B100 - Siemens 100A 1-Pole Molded Case Circuit Breaker 277V Bolt-On HED Frame

HED41B100

HED41B100 is a Siemens 1-pole molded case circuit breaker rated for 100 amps and 277 volts AC with bolt-on mounting.This circuit breaker features a thermal magnetic trip unit with long time and instantaneous trip functions, designed for high interrupting capacity applications. It has a 65kA interrupt rating at 277V, HED frame type, and load side lug terminals. Suitable for residential, commercial, and industrial use, it provides reliable protection and is compatible with current and legacy Siemens circuit breakers.

• Amperage: 100A
• Voltage: 277V AC
• Poles: 1
• Frame Type: HED
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA @ 277V
• Trip Unit: Thermal Magnetic with long time and instantaneous functions
• Connection: Load side lug terminals
• Phase: Single phase
• Certifications: UL Listed
• Application: Residential, Commercial, Industrial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HED41B100
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HED
• Voltage : 277
• Amperage : 100
• Phase : 1
• Poles : 1
• AIC rating : 25kA@277V
• Connection : Lug In Panelboard
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 125A/ED
• MCM Size : Min. Wire Size 10 AWG Max. Wire Size 4 AWG
• Breaker Type : High Interrupting Capacity
• Protection : Thermal Magnetic
• Phase Connection : Any

Product Data

• UPC : 783643209930
• GTIN : 00783643209930
• Country of Origin : Mexico
• Weight : 1.1
• Panel Type : SB Switchboards, Sentron Panelboards
• Standards : IEC 60947-2, UL 489
• Wire Size : ?6 - 1/0AWG (CU/AL)
