HDA36125SA - Square D 125A 600VAC 3 Pole Thermal Magnetic I-Line Molded Case Circuit Breaker

HDA36125SA

HDA36125SA is a Square D 3 pole thermal magnetic molded case circuit breaker rated for 125 amps and 600VAC voltage. It features an I-Line style plug-in connection and is designed for reliable circuit protection.This circuit breaker belongs to the PowerPact H series with a frame type HDA. It provides long time and instantaneous trip functions with an interrupting rating of 18kA at 480V. The breaker supports line and load lug terminal connections and accommodates wire gauges from AWG 14 to AWG 3/0 for aluminum or copper conductors. It is UL, CSA, CE, NEMA, NOM, IEC, and RoHS certified.

Key Specifications
• Amperage: 125A
• Voltage Rating: 600VAC
• Poles: 3
• Interrupting Rating: 18kA @ 480V
• Frame Type: HDA (PowerPact H)
• Connection Type: I-Line Style Plug-In
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Terminal Connection: Line and Load Lug
• Wire Gauge Range: AWG 14 to AWG 3/0 Aluminum/Copper
• Certifications: UL, CSA, CE, NEMA, NOM, IEC, RoHS
• Actuator Type: Toggle
• Phase: 3

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36125SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 7.85902E+11
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
