HDA36090 - Square D 90 Amp 600 Volt 3 Pole Molded Case Circuit Breaker PowerPact H Frame

HDA36090

HDA36090 is a Square D 3-pole molded case circuit breaker rated for 90 amps and 600 volts, designed for reliable power distribution protection.This circuit breaker features a PowerPact H frame with thermal magnetic trip unit, plug-on mounting type, and a 14kA interrupt rating at 600V. It is UL, CSA, and CE certified, suitable for use in Class 611/612 I-Line panelboards and switchboards. The breaker supports ABC phase connection and is designed for industrial and commercial applications.

• Amperage: 90A
• Voltage Rating: 600V AC / 250V DC
• Poles: 3
• Mounting Type: Plug-On (I-Line)
• Interrupt Rating: 14kA at 600V
• Frame/Series: PowerPact H (HDA)
• Trip Unit: Thermal Magnetic
• Phase Connection: ABC
• Certifications: UL Listed, CSA, CE
• Application: Power Distribution
• Compatible with Class 611/612 I-Line Panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901422266
• GTIN : 00785901422266
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.58 lb
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
