HDA36080 - Square D 80A 600V 3-Pole I-Line Molded Case Circuit Breaker Thermal Magnetic

HDA36080

HDA36080 is a Square D 3-pole molded case circuit breaker rated for 80 amps and 600 volts with I-Line plug-on mounting and thermal magnetic trip unit.This circuit breaker features a PowerPact H frame with a 14kA interrupt rating at 600 VAC and is UL listed, CSA certified, and IEC rated. It supports 3-phase ABC connection and is designed for reliable protection in industrial and commercial electrical systems. The breaker has a trip setting hold of 800A and trip at 1450A, suitable for I-Line panelboards.

Key Specifications
• Amperage: 80 Amps
• Voltage: 600 VAC / 250 VDC
• Poles: 3
• Mounting Type: I-Line Plug-On
• Interrupt Rating: 14kA @ 600 VAC, 18kA @ 480 VAC, 25kA @ 240 VAC
• Frame/Series: PowerPact H
• Trip Unit: Thermal Magnetic
• Phase: 3 (ABC)
• Certifications: UL Listed, CSA Certified, IEC Rated
• Trip Range: Hold 800A, Trip 1450A
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HDA36080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : ABC



Product Data

• UPC : 785901507277
• GTIN : 00785901507277
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.49
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
