HDA36020 - Square D 20 Amp 600/690VAC 3 Pole I-Line Circuit Breaker PowerPacT H Frame

HDA36020

HDA36020 is a Square D 3 Pole 20 Amp thermal magnetic molded case circuit breaker designed for reliable power distribution.This PowerPacT H frame breaker features a 600/690VAC voltage rating, 18kA interrupting capacity at 480VAC, and an I-Line style plug-in mounting. It includes LI long-time and instantaneous trip functions, load side lug terminal connections, and is certified to UL, CSA, CE, NEMA, NOM, and IEC standards.

• Amperage: 20 Amps
• Voltage: 600/690VAC
• Poles: 3
• Mounting Type: I-Line Bracket Plug-In
• Interrupt Rating: 18kAIC at 480VAC
• Series/Frame: PowerPacT H (HDA Frame)
• Trip Unit: Thermal Magnetic with LI Long-Time and Instantaneous Trip
• Terminal Connection: Load Side Lug
• Approvals: UL, CSA, CE, NEMA, NOM, IEC
• Wire Gauge: AWG 14 to AWG 3/0 Aluminum/Copper
• Operating Temperature: -25 to 70 °C
• Actuator Type: Toggle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA36020
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901405245
• GTIN : 00785901405245
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.47 lb
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
