HDA261104 - Square D PowerPact H 110A 2-Pole 600V Molded Case Circuit Breaker

SKU: HDA261104-New
Condition: New
Price:
$1,047.45
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

HDA261104 - Square D PowerPact H 110A 2-Pole 600V Molded Case Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
HDA261104 - Square D PowerPact H 110A 2-Pole 600V Molded Case Circuit Breaker - Essential Electric Supply

Description

HDA261104


HDA261104 is a Square D PowerPact H-frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 2-pole breaker features a 110A current rating and is rated for 600V AC, making it suitable for a wide range of applications. It utilizes a thermal-magnetic trip unit for precise overload and short-circuit protection, and is designed for I-Line style plug-in mounting. The breaker is UL listed and suitable for reverse fed applications, offering robust performance and safety. This circuit breaker is built with a current limiting design and features line lug load terminals for secure connections. It is part of the PowerPact H series, known for durability and high interrupting capacity. The breaker is suitable for use in panelboards and switchgear where dependable circuit protection is required.
  • Part Number: HDA261104
  • Manufacturer: Square D
  • Series/Frame: PowerPact H
  • Amperage: 110A
  • Voltage: 600V AC
  • Poles: 2
  • Mounting Type: I-Line Style Plug-In
  • Interrupt Rating: 18kA @ 480V
  • Trip Unit: Thermal Magnetic
  • Certifications: UL Listed
  • Application: Panelboard, Switchgear
  • Features: Current Limiting, Reverse Fed Suitable
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: HDA261104
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : HDA
  • Voltage : 600
  • Amperage : 110
  • Phase : 1
  • Poles : 2
  • AIC rating : 18kA@480V
  • Connection : I-Line Style Plug-In
  • Functions : Long Time and Instantaneous Trip
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901912309
  • Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight : 3.001
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
