Product Info
- Manufacturer: Square D
- Sub-Category: Molded Case
Description
HDA261004
The Square D HDA261004 is a Molded Case Circuit Breaker. This type HDA circuit breaker is a member of The Powerpact family. The HDA261004 is a 2 pole, 600 Volt, 100 amp rated circuit breaker, with an AIC rating of 18kA@480V. The HDA261004 is manufactured by Square D. The HDA261004 uses a I-Line Style Plug-In connection. Includes Thermal Magnetic protection. Every part Essential Electric sells is also backed by our industry-leading gold standard 2-year warranty.
Specifications
- Part Number: HDA261004
- Manufacturer : Square D
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HDA
- Voltage : 600
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous
- Frame Size : H Frame
- Temp Rating : 28-158 °F (-2-70 °C)
Product Data
- UPC : 785901754350
- GTIN : 00785901754350
- Country of Origin : United States
- Dimensions : Height 6.42 in (163 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 3
- Certification : CE, IEC, CSA, UL
- Wire Size : AWG 14...AWG 3/0 aluminum/copper terminal
