HDA260601 - Square D 60 Amp 2 Pole 600V I-Line Molded Case Circuit Breaker, PowerPact H Frame, Thermal Magnetic Trip, UL Listed

HDA260601

HDA260601 is a Square D 2 pole molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This thermal magnetic circuit breaker features a 60 Amp rating, 600V AC voltage, and I-Line plug-in mounting for easy installation in compatible panelboards. It is part of the PowerPact H series, offering robust performance with long-time and instantaneous trip functions, and is UL listed for safety and compliance.

Key Specifications
• Amperage: 60A
• Voltage: 600V AC
• Poles: 2
• Mounting Type: I-Line style plug-in
• Interrupt Rating: 25kAIC at 240VAC, 18kAIC at 480VAC, 14kAIC at 600VAC
• Series/Frame: PowerPact H
• Trip Unit: Thermal magnetic (LI – Long-time and Instantaneous)
• Certifications: UL Listed
• Connection: A & B phase
• Approvals: CSA, CE, IEC (varies by region)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA260601
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901419037
• GTIN : 00785901419037
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
