HCTR6 - Edison Fuses 6A 600VAC Class CC Time-Delay Current-Limiting Fuse

HCTR6

HCTR6 is a 6 amp, 600 VAC Class CC time-delay current-limiting fuse designed for control circuit transformer protection.This Edison HCTR series fuse features a rejection style ferrule design with a 1-1/2 inch length and 13/32 inch diameter. It provides a high interrupt rating of 200kA RMS symmetrical at 600 VAC, meeting UL 248-4 and CSA Class CC standards. The fuse offers time-delay characteristics suitable for high inrush current applications and protects downstream components from thermal and magnetic short-circuit damage.

Key Specifications
• Amperage: 6 Amps
• Voltage Rating: 600 VAC
• Fuse Class: CC
• Time-Delay: Yes
• Current Limiting: Yes
• Interrupt Rating: 200,000 A RMS Symmetrical
• Mounting Type: Ferrule (Rejection Style)
• Fuse Length: 1-1/2 inches
• Diameter: 13/32 inches
• Certifications: UL Listed, CSA Certified
• Agency File Numbers: UL E162363, CSA 53787
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HCTR6
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Voltage : 600
• Amperage : 6
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1



Product Data

• UPC : 78263480224
• GTIN : 00782634802242
• Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
• Weight : 0.1
