HCTR2 - Edison 2 Amp 600 Volt Class CC Time-Delay Fuse 1-Pole 200kA Interrupt Rating

HCTR2

HCTR2 is a 2 Amp, 600 Volt Class CC time-delay fuse from Edison Fuses designed for current-limiting and high inrush applications.This fuse features a rejection style, non-indicating design with a 12-second delay at 200% overload, a 200 kA interrupting rating, and melamine tube construction with nickel-plated brass endcaps. It is UL listed and CSA certified for reliable circuit protection in control power transformers and inductive loads.

Key Specifications
• Amperage: 2 Amp
• Voltage Rating: 600 Volts AC
• Fuse Type: Class CC
• Response Time: Time Delayed (12 sec at 200%)
• Interrupt Rating: 200,000 RMS Symmetrical Amps (200 kAIC)
• Poles: 1
• Mounting Type: Rejection style cartridge
• Construction: Melamine tube with nickel-plated brass endcaps
• Certifications: UL Listed, CSA Certified, CE Compliant
• Fuse Series: HCTR

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HCTR2
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : HCTR Series
• Type : HCTR
• Voltage : 600
• Amperage : 2
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 782634802150
• GTIN : 00782634802150
• Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
• Weight : 0.1 lb
