HCTR2.5 - Edison Fuses 2.5A 600VAC Class CC Time-Delay Current Limiting Fuse

HCTR2.5

HCTR2.5 is a 2.5 amp, 600 VAC Class CC time-delay current limiting fuse from Edison Fuses designed for feeder and branch circuit protection.HCTR2.5 features a ferrule mounting type and provides a high interrupt rating of 200kA RMS symmetrical, ensuring reliable protection for control circuits. This fuse complies with UL and CSA certifications and is RoHS compliant. It measures 1-1/2 inches in length with a 13/32 inch diameter, suitable for Class CC fuse holders.

Key Specifications
• Amperage: 2.5A
• Voltage Rating: 600 VAC
• Fuse Type: Class CC
• Time-Delay: Yes
• Current Limiting: Yes
• Mounting Type: Ferrule
• Interrupt Rating: 200kA RMS Symmetrical
• Length: 1-1/2 inches
• Diameter: 13/32 inches
• Certifications: UL, CSA C22.2, RoHS compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HCTR2.5
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Voltage : 600
• Amperage : 2.5
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 78263480217
• GTIN : 00782634802174
• Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
• Weight : 0.1
