HCLR25 - Edison Fuses 25A 600V Class CC Fast-Acting Current Limiting Fuse, 200kA Interrupt Rating, Ferrule Mount

HCLR25

HCLR25 is a compact, fast-acting, current-limiting Class CC fuse from Edison Fuses, designed for reliable branch circuit protection in demanding applications.

This Edison HCLR series fuse offers a 25A rating at 600VAC, with a high interrupting capacity of 200,000A RMS symmetrical. Its fast-acting design responds quickly to both overload and short-circuit conditions, making it ideal for lighting and resistive heating loads. The single-barrel, ferrule-mounted construction ensures easy installation and space-saving benefits in panelboards and control circuits.

Key Specifications
• Part Number: HCLR25
• Manufacturer: Edison Fuses
• Amperage: 25A
• Voltage: 600VAC
• Poles: 1
• Mounting Type: Ferrule
• Interrupt Rating: 200,000A RMS symmetrical
• Series/Frame: HCLR
• Trip Unit: Fast-acting
• Certifications: UL Listed (Class CC, Guide JDDZ, File E162363), CSA Certified (HRCI-MISC per C22.2 No. 248.4), CE Compliant
• Application: Branch circuit protection for lighting, resistive heating
• Response Time: Fast-acting
• Design: Current-limiting, compact, single barrel

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HCLR25
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : HCLR Series
• Type : HCLR
• Voltage : 600
• Amperage : 25
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 782634420729
• GTIN : 00782634420729
• Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
• Weight : 0.001
