HCLR20 - Edison Fuses 20A 600V Class CC Fast Acting Fuse

HCLR20

HCLR20 is a 20 amp, 600 volt Class CC fast-acting fuse from Edison Fuses designed for branch circuit protection.This fuse features a compact design with a 0.41 inch diameter and 1.50 inch length, providing fast response to overload and short-circuit conditions. It is rated for 600 VAC and 300 VDC (for 15A and 20A), with an interrupting rating of 200,000 RMS symmetrical amps. The HCLR20 is UL Listed, CSA Certified, and CE Compliant, making it suitable for lighting and resistive heating load applications.

Key Specifications
• Amperage: 20A
• Voltage Rating: 600 VAC, 300 VDC
• Fuse Type: Class CC, Current Limiting
• Response Time: Fast Acting
• Interrupting Rating: 200,000 RMS Symmetrical Amps
• Dimensions: 0.41 inch diameter, 1.50 inch length
• Material: Melamine body, brass end caps
• Certifications: UL Listed, CSA Certified, CE Compliant
• Mounting Type: Ferrule
• Application: Branch circuit protection, lighting, resistive heating loads
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HCLR20
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : HCLR Series
• Type : HCLR
• Voltage : 600
• Amperage : 20
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1



Product Data

• UPC : 782634420712
• GTIN : 00782634420712
• Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
• Weight : 0.001
