Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
HCLR1.5
HCLR1.5 is a 1.5 amp, 600 volt Class CC fast acting current limiting fuse from Edison Fuses designed for branch circuit protection.HCLR1.5 features a compact rejection style design suitable for lighting and resistive heating loads, with a 200 kA interrupt rating and UL, CSA, and CE certifications.
- Amperage Rating: 1.5 Amps
- Voltage Rating: 600 VAC
- Fuse Class: Class CC
- Fuse Type: Fast Acting
- Interrupt Rating: 200,000 RMS Symmetrical Amps (200 kAIC)
- Mounting Type: Rejection Style
- Fuse Body Material: Melamine tube with nickel-plated brass endcaps
- Dimensions: Approximately 1.5 inches length, 13/32 inch diameter
- Applications: Lighting, resistance heating circuits
- Certifications: UL Listed, CSA Certified, CE Compliant
- Non-indicating fuse
Specifications
- Part Number: HCLR1.5
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 600
- Amperage : 1.5
- AIC rating : 200kA@600V
- Diameter : 0.41
- Class Rating : CC
- Barrels : 1
Product Data
- UPC : 78263442059
- GTIN : 00782634420590
- Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
- Weight : 0.001
