HBL9451C - Hubbell 50A 125/250V 3-Pole 4-Wire NEMA 14-50P Straight Blade Plug

HBL9451C

HBL9451C is a heavy-duty, industrial/commercial grade straight blade plug designed for reliable power connections in demanding environments. This Hubbell device features a 3-pole, 4-wire grounding configuration with a NEMA 14-50P rating, supporting 50A at 125/250V. Constructed from supertough nylon, it offers secure gripping ribs and a durable composite housing for long-lasting performance. The plug is suitable for wire sizes from #12 AWG to #4 AWG and is rated for continuous operation from -40°C to 75°C. It meets UL 498 and CSA standards for safety and reliability. Key Specifications

• Part Number: HBL9451C
• Manufacturer: Hubbell Wiring Device-Kellems
• Amperage Rating: 50 A
• Voltage Rating: 125/250 VAC
• Number of Poles: 3
• Number of Wires: 4
• Mounting Type: Cord Mount
• Interrupt Rating: Full rated current
• Series/Frame: Extra Heavy Duty
• Terminal Type: Screw, Threaded
• Wire Size: #12 AWG to #4 AWG
• Operating Temperature: -40°C to 75°C
• Enclosure Rating: IP20
• Standards: UL 498, CSA, NEMA WD-1, WD-5
• Color: Black/White
• Material: Composite, Nylon
• Dielectric Strength: 2,000V minimum
• UPC: 783585015323

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HBL9451C
• Manufacturer : Hubbell
• Brand : Hubbell
• Category : Conduit & Fittings
• Item Subcategory : Pin & Sleeve
• Voltage : 125/250 125/250

Product Data

• UPC : 783585015323
• GTIN : 00783585015323
• Dimensions : 4.13 in L x 2.88 in W 4.13 x 2.88 x 2.88 4.13 x 2.88 x 2.88 in
• Weight : 5.19
