HBL8450A - Hubbell 50A 250V 3-Pole 4-Wire NEMA 15-50R Straight Blade Receptacle Black

Save $72.14
SKU: HBL8450A-New
Condition: New
Price:
$123.86 $196.00
Stock:
45 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

HBL8450A Hubbell Industrial Flush Receptacle 3-Pole 4-Wire 50A 250V NEMA 15-50R - Essential Electric Supply
HBL8450A - Hubbell 50A 250V 3-Pole 4-Wire NEMA 15-50R Straight Blade Receptacle Black - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
HBL8450A Hubbell Industrial Flush Receptacle 3-Pole 4-Wire 50A 250V NEMA 15-50R - Essential Electric Supply
HBL8450A - Hubbell 50A 250V 3-Pole 4-Wire NEMA 15-50R Straight Blade Receptacle Black - Essential Electric Supply

Description

HBL8450A


HBL8450A is a Hubbell heavy-duty straight blade receptacle rated for 50 amps and 250 volts AC, designed for 3-phase power applications.This specification grade receptacle features a 3-pole, 4-wire grounding configuration with a NEMA 15-50R rating. It supports back and side wired screw terminals accommodating #12 AWG to #4 AWG copper wire. The device is black, industrial grade, and CSA certified, UL listed, and NEMA WD-6 compliant. It withstands a dielectric strength of 2000V minimum and is suitable for indoor dry environments with an IP20 rating.
    Key Specifications
    • Amperage: 50 A
    • Voltage: 250 VAC
    • Poles: 3
    • Wires: 4 (including ground)
    • NEMA Rating: 15-50R
    • Mounting Type: Screw Mount
    • Connection: Back and Side Wired
    • Wire Size: #12 AWG to #4 AWG copper
    • Dielectric Strength: 2000 V minimum
    • Certifications: CSA Certified, UL Listed, NEMA WD-6 Compliant
    • Color: Black
    • Phase: Three Phase
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: HBL8450A
  • Manufacturer : Hubbell
  • Brand : Hubbell
  • Category : Conduit & Fittings
  • Item Subcategory : Pin & Sleeve
  • Family : HBL
  • Voltage : 250 250

Product Data

  • UPC : 783585015156
  • GTIN : 00783585015156
  • Dimensions : 2.75 in L x 2.44 in W x 3.69 in H 3.69 in H x 2.75 in W x 2.44 in D
  • Weight : 0.3
