Product Info
- Manufacturer:Hubbell
- Sub-Category:Locking Devices
Description
HBL3100C6W
HBL3100C6W is a heavy-duty, watertight IEC pin and sleeve connector rated for 100 amps and 250 volts AC with 2 poles and 3 wires.This industrial-grade female connector body features a rugged blue nylon housing with brass contacts, designed for high ampacity connections. It includes terminal screws and a self-closing gasketed cover for watertight protection, meeting IP67 ingress protection standards. Certified UL Listed and CSA Certified, it withstands 3000V AC dielectric voltage and is suitable for harsh environments with operating temperatures from -40°C to 75°C.
- Amperage: 100A
- Voltage: 250V AC
- Poles/Wires: 2-Pole, 3-Wire
- Housing Material: Blue Nylon (Zytel ST801)
- Contacts: Brass
- Mounting Type: Cord Mounted
- Interrupt Rating: Certified for current interrupting at full rated current
- Ingress Protection: IP67 Watertight
- Certifications: UL Listed, CSA Certified
- Dielectric Voltage Withstand: 3000V AC
- Operating Temperature: -40°C to 75°C
- Series: Hubbell HBL IEC 60309
Specifications
- Part Number: HBL3100C6W
- Manufacturer : Hubbell
- Brand : Hubbell
- Category : Conduit & Fittings
- Item Subcategory : Locking Devices
- Voltage : 250 250
Product Data
- UPC : 783585403045
- GTIN : 00783585403045
- Dimensions : 13.57 in L x 5.72 in H
- Weight : 0.5
