HBL2720 - Hubbell 30A 250V 3-Phase 4-Wire L15-30R Twist-Lock Flush Mount Industrial Receptacle, NEMA 4X/12/IP20, Black

HBL2720

HBL2720 Hubbell industrial-grade locking receptacle delivers reliable 3-phase power in demanding environments.

This heavy-duty, flush-mount Twist-Lock receptacle features a 3-pole, 4-wire grounding configuration, NEMA L15-30R rating, and is designed for 30A, 250V AC applications. Constructed with a nylon body and all-brass mounting system for superior corrosion resistance, it is certified for current interrupting at full rated current and withstands a minimum dielectric voltage of 2,000V. The enclosure meets NEMA 4X/12/IP20 standards for protection against dust, water, and corrosion, making it suitable for harsh industrial settings. Wire restraint recesses help maintain secure connections, and face color coding aids in proper device mating.

Key Specifications
• Amperage: 30A
• Voltage: 250V AC, 3-Phase
• Poles: 3
• Mounting Type: Flush, single screw
• Interrupt Rating: Certified for full rated current interrupting
• Series/Frame: HBL
• Trip Unit: Not applicable (receptacle only)
• Certifications: UL, CSA, NEMA 4X/12/IP20, RoHS compliant
• Wire Size: Accepts #16 AWG to #8 AWG solid or stranded copper
• Material: Nylon body, brass contacts and grounding
• Temperature Range: -40°C to 75°C
• Color: Black
• Dimensions: 3.28 x 1.7 x 1.31 in

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HBL2720
• Manufacturer : Hubbell
• Brand : Hubbell
• Category : Conduit & Fittings
• Item Subcategory : Twist-Lock
• Family : HBL
• Voltage : 250 250

Product Data

• UPC : 783585236131
• GTIN : 00783585236131
• Dimensions : 3.28 in H x 1.7 in W x 1.23 in D 3.28 x 1.7 x 1.31 in
• Weight : 5.19
