GVAN203 - Square D TeSys GV2/GV3 Auxiliary Contact Block 2NO 5A 690VAC Side Mount

GVAN203

GVAN203 is a Square D TeSys GV2/GV3 series auxiliary contact block with 2 normally open (2NO) contacts rated for 5A at 690VAC, designed for side mounting on motor circuit breakers.This auxiliary contact block provides reliable switching for signaling and control circuits in motor starters and circuit breakers. It features a compact design compatible with TeSys GV2 and GV3 manual motor starters, with a minimum switching current of 5 mA and rated insulation voltage of 600 V (UL 508) and 690 V (IEC). It mounts on the left-hand side of the circuit breaker and supports up to 6A operational current at 690 VAC and 6A at 240 VDC. The GVAN203 complies with IEC 60947 and CSA C22.2 No 14 standards.

Key Specifications
• Manufacturer: Square D
• Part Number: GVAN203
• Series/Frame: TeSys GV2/GV3
• Contact Configuration: 2 Normally Open (2NO)
• Rated Current: 5A
• Rated Voltage: 690 VAC / 240 VDC
• Mounting Type: Side Mount
• Minimum Switching Current: 5 mA
• Rated Insulation Voltage: 600 V (UL 508), 690 V (IEC)
• Standards: IEC 60947, CSA C22.2 No 14

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GVAN203
• Manufacturer : Schneider Electric
• Brand : Schneider Electric

Product Data

• Dimensions : 3.5 in (89 mm) x 0.4 in (9.3 mm) x 2.6 in (66 mm) (Height x Width x Depth)
• Weight : 0.09
