GV2ME03 - Schneider Electric TeSys GV2 Manual Motor Starter, 0.4–0.63 A, 3-Pole, 690 V AC

GV2ME03

GV2ME03 is a manual motor starter manufactured by Schneider Electric as part of the TeSys GV2 series. It provides thermal-magnetic protection for motors rated between 0.4 and 0.63 A, offering reliable protection against short circuits, overloads, and phase loss. Designed for compact control panels, the GV2ME03 combines circuit protection and manual motor control in a single device. This motor starter features a toggle actuator for ON/OFF control, a trip indicator for visual status, and terminals compatible with TeSys accessories such as auxiliary contacts and undervoltage releases.

• Part Number: GV2ME03
• Manufacturer: Schneider Electric
• Series / Family: TeSys GV2
• Product Type: Manual Motor Starter
• Poles: 3
• Thermal Adjustment Range: 0.4–0.63 A
• Voltage Rating: Up to 690 V AC
• Trip Unit Type: Thermal-magnetic
• Mounting Type: DIN rail or panel mount
• Control Type: Toggle lever (ON/OFF/Trip indication)
• Application: Direct-on-line (DOL) motor starting and protection for small motors
• Certifications: UL 60947-4-1 Listed, CSA Certified, IEC 60947-2/4-1 Compliant, CE Marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GV2ME03
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : TeSys GV2
• Type : GV2
• Voltage : 600
• Amperage : 0.4
• Phase : 3
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Nema Rating : 00

Product Data

• UPC : 038911034299
• GTIN : 03389110342994
• Country of Origin : Thailand
• Dimensions : 3.5 in (89 mm) x 1.8 in (45 mm) x 3.09 in (78.5 mm) (Height x Width x Depth)
• Weight : 0.489
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : ATEX Compliant, BV, CCC, CSA, DNV-GL, EAC, EN/IEC 60947-2, EN/IEC 60947-4, LROS, RINA, UKCA, UL Listed
