Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
GSC1/10
GSC1/10 is a Mersen Ferraz Shawmut time delay glass fuse rated at 1/10 amp and 250 volts AC with a 5 mm x 20 mm size.GSC1/10 features a glass body with time-delay characteristics, designed for circuit protection in electronic applications. It has an interrupting rating of 100,000 AIC at 250 VAC and is UL and CSA recognized. This fuse is suitable for PC mounting or clip mounting and provides reliable protection with a compact form factor.
- Amperage: 1/10 Amp
- Voltage Rating: 250 VAC
- Fuse Type: Time Delay
- Body Material: Glass
- Size: 5 mm x 20 mm
- Interrupting Rating: 100,000 AIC @ 250 VAC
- Mounting Type: Clip or PC Mount
- Certifications: UL Recognized, CSA Certified
- Series: GSC
- Physical Length: Approximately 20 mm
- Diameter: 5 mm
Specifications
- Part Number: GSC1/10
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Type : GSC
- Voltage : 250
- Amperage : 1
- AIC rating : 100A@250V
- Connection : Ferrule
- Diameter : 5
- Barrels : 1
- Velocity : Time Delay
Product Data
- UPC : 782001765675
- Weight : 0.08
