Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
GSA6-1/4
GSA6-1/4 is a 6.25 Amp, 250 Volt ceramic time delay fuse designed for low voltage applications.This cylindrical fuse features a 1/4 inch diameter and 1-1/4 inch overall length with a ceramic tube construction for durability and reliable performance. It provides time delay protection to allow temporary current surges without blowing, making it suitable for motor and transformer circuits. The fuse has an interrupting rating of 200,000 AIC at 250 VAC.
- Amperage: 6.25 Amps
- Voltage Rating: 250 Volts AC
- Fuse Type: Ceramic Time Delay
- Dimensions: 1/4 inch diameter x 1-1/4 inch length
- Interrupting Rating: 200kA at 250 VAC
- Mounting Type: Holder
- Single Pole
- Series: GSA
Specifications
- Part Number: GSA6-1/4
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : GSA Series
- Type : GSA
- Voltage : 250
- Amperage : 6
- AIC rating : 200kA@250V
- Connection : Ferrule
- Diameter : 14
- Barrels : 1
- Velocity : Time-Delay
Product Data
- Weight : 25
