Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
GHC1020
GHC1020 is an Eaton Series C NEMA G-frame molded case circuit breaker designed for reliable branch circuit protection.GHC1020 features a 20 Amp rating, 1-pole configuration, and operates at 277 Vac and 125 Vdc. It uses a fixed thermal-magnetic trip unit and is cable-mounted for easy installation. This breaker is part of Eaton's Series C line, known for meeting or exceeding North American standards and suitable for panelboards, switchboards, motor control centers, and busway applications.
- Amperage: 20 Amp
- Voltage: 277 Vac, 125 Vdc
- Poles: 1
- Mounting Type: Cable
- Interrupt Rating: 65kA @ 120 Vac, 14kA @ 277 Vac
- Trip Unit: Fixed Thermal-Magnetic
- Series/Frame: Series C, NEMA G-frame
- Type: GHC
- Application: Branch circuit protection
- Certifications: Meets or exceeds North American standards
Specifications
- Part Number: GHC1020
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : GHC
- Voltage : 277
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 14kA@277V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Frame Size : G Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679173961
- GTIN : 00786679173961
- Country of Origin : Dominican Republic
- Dimensions : 2.63 in x 4.88 in x 1 in (Length/Depth x Height x Width)
- Weight : 0.75
- Certification : UL Listed
