GHB3060V - Eaton 60 Amp 480Y/277 VAC 3 Pole Molded Case Circuit Breaker, Fixed Thermal/Magnetic Trip, 14/65 kA Interrupt

GHB3060V

GHB3060V is a 60 Amp, 3 Pole molded case circuit breaker from Eaton's Series C Type GHB, designed for reliable circuit protection in panelboards.This Eaton GHB3060V circuit breaker features a fixed thermal and fixed magnetic trip unit, suitable for 480Y/277 VAC and 125/250 VDC applications. It offers a high interrupt rating of 14 kA at 480 VAC and 65 kA at 277 VAC, ensuring robust fault current interruption. The breaker is bolt-on mounted and UL listed for safety and performance compliance.

Key Specifications
• Amperage: 60 Amp
• Voltage Rating: 480Y/277 VAC, 125/250 VDC
• Poles: 3 Pole
• Interrupt Rating: 14 kA @ 480 VAC, 65 kA @ 277 VAC
• Trip Unit: Fixed Thermal/Fixed Magnetic
• Mounting Type: Bolt-On
• Series/Frame: Eaton Series C Type GHB
• Certifications: UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: GHB3060V
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic



Product Data

• UPC : 78211604752
• GTIN : 00782116047529
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.8
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 554
• Certification : CSA Certified, UL Listed
