GHB3050V - Eaton Series C G-Frame 3-Pole 50A 480Y/277V Molded Case Circuit Breaker, Fixed Thermal Magnetic Trip, UL Listed

GHB3050V

GHB3050V is a complete Eaton Series C G-frame molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This three-pole breaker features a fixed thermal magnetic trip unit, 50A amperage rating, and is rated for 480Y/277V AC and 125/250V DC systems. It is part of Eaton's trusted Series C family, offering robust performance and easy installation in panelboards and switchgear. The GHB3050V is UL Listed and complies with Federal Specifications Classification W-C375B, ensuring quality and safety for critical electrical distribution.

Key Specifications
• Part Number: GHB3050V
• Manufacturer: Eaton
• Series/Frame: Series C, G-frame
• Amperage: 50A
• Voltage: 480Y/277V AC, 125/250V DC
• Poles: 3
• Mounting Type: Bolt-on (fixed)
• Interrupt Rating: 14kA @ 480V AC
• Trip Unit: Fixed thermal magnetic
• Certifications: UL Listed
• Compliance: Federal Specifications Classification W-C375B
• Frequency: 50/60 Hz

At Essential Parts

Specifications

• Part Number: GHB3050V
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 78211604750
• GTIN : 00782116047505
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.8
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 550
• Certification : CSA Certified, UL Listed
