Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
GHB3030V
GHB3030V is a 3 pole, 30 amp molded case circuit breaker from Eaton's Series C family designed for 480Y/277VAC and 125/250VDC applications.This Eaton GHB3030V circuit breaker features a fixed thermal/fixed magnetic trip unit, a 14kA interrupt rating at 480VAC, and a 65kA interrupt rating at 240VAC. It is a bolt-on type breaker suitable for industrial and commercial power distribution systems, UL listed and compliant with federal specifications W-C375B.
- Amperage: 30 Amps
- Voltage Rating: 480Y/277VAC, 125/250VDC
- Poles: 3
- Interrupt Rating: 14kA @ 480VAC, 65kA @ 240VAC
- Trip Unit: Fixed Thermal/Fixed Magnetic
- Mounting Type: Bolt-On
- Series/Frame: Series C, GHB Frame
- Certifications: UL Listed, Federal Spec W-C375B
- Terminal Type: Screw Terminals
Specifications
- Part Number: GHB3030V
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : GHB
- Voltage : 480
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Terminal Connection : Screw Clamp
- Frame Size : 100/GHB
- Temp Rating : 28-158 ¡F (-2-70 ¡C)
- Breaker Type : Standard
- Protection : Thermal Magnetic
Product Data
- UPC : 78211604749
- GTIN : 00782116047499
- Country of Origin : Dominican Republic
- Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
- Weight : 1.75
- Panel Type : Eaton Powerline Panelboards
- Standards : UL 537
- Certification : CSA Certified, UL Listed
