GHB3020V - Eaton 20A 3-Pole 480Y/277VAC Molded Case Circuit Breaker, Series C G-Frame, Fixed Thermal/Magnetic Trip

GHB3020V

This 3-pole breaker is rated for 20 amps and designed for use at 480Y/277 VAC and 125/250 VDC, suitable for 50/60 Hz applications. It features a G-frame construction and offers interrupt ratings of 14 kA at 480Y/277 VAC and 65 kA at 240 VAC. The breaker is UL Listed and designed for bolt-on panelboard mounting.

Key Specifications
• Amperage: 20 Amp
• Voltage: 480Y/277 VAC, 125/250 VDC
• Poles: 3
• Interrupt Rating: 14 kA at 480Y/277 VAC, 65 kA at 240 VAC
• Series/Frame: Eaton Series C, G-Frame
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting Type: Bolt-On Panelboard
• Frequency: 50/60 Hz
• Certifications: UL Listed
• Weight: Approximately 1.75 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: GHB3020V
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic



Product Data

• UPC : 78211604746
• GTIN : 00782116047468
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.75
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 529
• Certification : CSA Certified, UL Listed
