GHB3020S1 - Westinghouse 20A 480V 3 Pole Molded Case Circuit Breaker G Frame Thermal Magnetic

GHB3020S1

GHB3020S1 is a Westinghouse molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This 3 pole, 20 amp breaker operates at 480Y/277 VAC and 125/250 VDC with a G frame and thermal magnetic trip unit. It features a 14kA interrupting rating at 480 VAC and 65kA at 240 VAC, bolt-on mounting, and includes a 120 VAC shunt trip. The breaker complies with IEC 157-1 standards and is suitable for reverse feed applications.

Key Specifications
• Amperage: 20 Amp
• Voltage: 480Y/277 VAC, 125/250 VDC
• Poles: 3
• Frame: G Frame (GHB Series)
• Interrupting Rating: 14kA @ 480 VAC, 65kA @ 240 VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: Bolt-On
• Includes 120 VAC Shunt Trip
• Standards: IEC 157-1
• Suitable for Reverse Feed Applications

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GHB3020S1
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 786679041994
• GTIN : 00786679041994
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 2
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 527
• Certification : CSA Certified, UL Listed
