Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
GGX20
GGX20 is a Mersen Ferraz Shawmut fast acting miniature fuse rated for 20 amps and 32 volts AC, designed for clip mounting.GGX20 features a 6.3 mm x 25.4 mm (1/4 inch diameter by 1 inch length) glass tube cartridge construction with ferrule terminals. It requires a fuse holder or clip for mounting and has an interrupt rating of 1 kA at 32 VAC. This fuse is UL approved and suitable for supplemental circuit protection in low voltage applications.
- Key Specifications
- Amperage: 20 A
- Voltage Rating: 32 V AC
- Fuse Type: Fast Acting Miniature Glass Tube
- Mounting Type: Requires Holder / Clip
- Fuse Size: 6.3 mm x 25.4 mm (1/4 inch x 1 inch)
- Interrupt Rating: 1 kA at 32 VAC
- Terminal Type: Ferrule
- Certifications: UL Approved
- Manufacturer: Mersen Ferraz Shawmut
Specifications
- Part Number: GGX20
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Type : GGX
- Voltage : 32
- Amperage : 20
- AIC rating : 32Vac
- Connection : Ferrule
- Diameter : 0.25
- Barrels : 1
- Velocity : Fast Acting
Product Data
- UPC : 078200120358
- GTIN : 00782001203580
- Weight : 0.08
