Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
GGC6/10
GGC6/10 is a Bussmann series cylindrical fuse designed for reliable low voltage circuit protection. This fuse features a 10 x 38 mm construction, rated at 6A and 250V AC, with a high breaking capacity of 120kA and class gG/gL protection. Suitable for use in modular fuse holders, it provides dependable equipment and cable protection in a wide range of industrial and commercial applications. This Eaton Bussmann fuse is constructed with a ceramic body and ferrule ends for secure mounting. It meets IEC 60269 standards and is CE marked, RoHS compliant, and suitable for use in circuits requiring fast-acting protection. The fuse is designed for easy installation and compatibility with standard fuse holders.
- Part Number: GGC6/10
- Manufacturer: Eaton Bussmann
- Amperage Rating: 6A
- Voltage Rating: 250V AC
- Fuse Size: 10 x 38 mm
- Breaking Capacity: 120kA
- Class: gG/gL
- Mounting Type: Ferrule End
- Construction: Ceramic
- Compliance: CE, RoHS, IEC 60269
- Application: Equipment and Cable Protection
- Watt Losses: 0.85W
Specifications
- Part Number: GGC6/10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : GGC Series
- Type : GGC
- Voltage : 250
- Amperage : 6
- AIC rating : 200kA@250Vac
- Connection : Ferrule
- Diameter : 0.25
- Barrels : 1
Product Data
- UPC : 782001769932
- Country of Origin : China
- Dimensions : x 1-1/2 in x
- Weight : 0.01
- Certification : UL, CSA
