GFN30 - Mersen Ferraz Shawmut 30A 32V 2-Barrel Midget Fuse Time Delay

GFN30

GFN30 is a midget class time-delay fuse rated for 30 amperes at 32 volts AC with a 10 kA interrupt rating. This cartridge fuse features a built-in pin indicator that pops out when the fuse operates, providing visual indication of a blown fuse or actuating a remote switch for signaling purposes.

The GFN30 is designed for low-voltage applications and offers a 12-second time delay at 200% of its rated amperage. It features a ferrule connection type with tin-plated copper terminals and is mounted via clip. The fuse body is constructed of polytube insulation material and measures 1.5 inches long by 0.41 inches in diameter. UL listed to Standard 248-14 and CSA certified to Standard C22.2 No. 248.14.

• Amperage Rating: 30 A
• Voltage Rating: 32 VAC
• Interrupt Rating: 10 kA
• Fuse Class: Midget
• Speed: Time Delay
• Indication System: Pin Indicator
• Connection Type: Ferrule
• Terminal Material: Tin-Plated Copper
• Mounting: Clip
• Body Material: Polytube
• Dimensions: 1.5 inches x 0.41 inches diameter
• Certifications: UL 248-14, CSA C22.2 No. 248.14

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GFN30
• Manufacturer : Mersen
• Brand : Mersen
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : GFN
• Type : GFN
• Voltage : 240 AC
• Amperage : 30
• AIC rating : 100kA@240V
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Diameter : 0.41
• Class Rating : Midget
• Configuration : Single
• Barrels : 2

Product Data

• UPC : 78200176780
• GTIN : 00782001767808
• Country of Origin : Mexico
• Weight : 3
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Certification : UL listed
