GFN2/10 - Mersen Ferraz Shawmut 0.2A 250VAC Time Delay Midget Fuse with Pin Indicator

GFN2/10

GFN2/10 - Mersen GFN midget time-delay fuse with visual pin indicator, rated at 2/10A and 250VAC.The GFN2/10 is a midget class fuse featuring time-delay characteristics and a built-in pin indicator that pops out upon operation for visual blown fuse indication. It uses ferrule terminals with tin-plated copper construction and measures 13/32 inch diameter by 1-1/2 inch length. Designed for supplemental protection in applications requiring time-delay and indication, such as solenoid circuits. Not for branch circuit protection.

• Ampere Rating: 2/10 A (0.2 A)
• Voltage Rating: 250 VAC
• Fuse Class: Midget
• Speed/Characteristic: Time Delay
• Indication: Visual Pin Indicator
• Connection Type: Ferrule
• Dimensions: 13/32 in x 1-1/2 in
• Interrupting Rating: 200 kA @ 250 VAC
• Certifications: UL 248-14 (E33925), CSA C22.2 No. 248.14
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GFN2/10
• Manufacturer : Mersen
• Brand : Mersen
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : GFN
• Type : GFN
• Voltage : 240 AC
• Amperage : 2
• AIC rating : 100kA@240V
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Diameter : 0.41
• Class Rating : Midget
• Configuration : Single
• Barrels : 1

Product Data

• UPC : 78200176153
• GTIN : 00782001761530
• Country of Origin : Mexico
• Weight : 3
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Certification : UL listed
