Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
GFN1/2
GFN1/2 - Mersen GFN midget time-delay fuse rated at 0.5A and 250VAC with ferrule terminals and visual indicator.The GFN1/2 is a midget class time-delay fuse featuring a built-in pin indicator that pops out to visually signal a blown fuse, suitable for supplemental protection in control and solenoid circuits. It offers 12 second time-delay at 200% rating, tin-plated copper ferrule terminals, clip mounting, and polytube body construction. Not intended for branch circuit protection.
- Ampere Rating: 0.5 A
- Voltage Rating: 250 VAC
- Fuse Class: Midget
- Speed: Time-Delay
- Mounting: Clip
- Terminal Type: Ferrule
- Indication: Visual Pin Indicator
- Body Material: PolyTube
- Dimensions: 0.41 in dia x 1.5 in length
- Frequency: 50/60 Hz
Specifications
- Part Number: GFN1/2
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : GFN
- Type : GFN
- Voltage : 240 AC
- Amperage : 1
- AIC rating : 100kA@240V
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Diameter : 0.41
- Class Rating : Midget
- Configuration : Single
- Barrels : 1
Product Data
- UPC : 78200176156
- GTIN : 00782001761561
- Country of Origin : Mexico
- Dimensions : x 1-1/2 in x
- Weight : 3
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Certification : UL listed
