Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
GDL10
GDL10 is a Mersen Ferraz Shawmut miniature glass fuse with a 10 ampere rating and 125 VAC voltage for time-delay protection.This fuse features a time-delay characteristic suitable for supplemental circuit protection. It has a glass body with dimensions of 6.3 x 32 mm (1/4 inch diameter by 1 1/4 inch length) and a ferrule connection type for clip mounting. The fuse is UL and CSA approved, RoHS compliant, and rated for an interrupting capacity of 10,000 AIC at 125 VAC.
- Key Specifications
- Amperage: 10 A
- Voltage Rating: 125 VAC
- Fuse Type: Time-Delay
- Fuse Size: 6.3 x 32 mm (1/4" x 1 1/4")
- Mounting Type: Clip
- Connection Type: Ferrule
- Body Material: Glass
- Interrupt Rating: 10,000 AIC @ 125 VAC
- Certifications: UL Listed, CSA Approved, RoHS Compliant
- Fuse Class: Supplemental
- Part Number: GDL10
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Type : GDL
- Voltage : 125
- Amperage : 10
- AIC rating : 10kA@125V
- Diameter : 0.25
- Barrels : 1
- Velocity : Time Delay
- UPC : 78200176338
- GTIN : 00782001763381
- Country of Origin : China
- Dimensions : x 1-1/4" x
- Weight : 0.08
- Certification : CSA, UL
